GENERAL INFORMATION
Product Code
NTM/4/40-55/840
Product Range
TEMPE PRO
Product Category
Surface Mount
Fixing Method
Surface /Suspended
IP Rating
23
IK Rating
Warranty
7 Years
DIMENSIONS/WEIGHT
Dimensions
W: 92 - H: 50 - DEPTH: - DIAMETER:
Cut-out Size (mm)
Product Weight (kg)
Construction
Body Material
Steel
Body Colour
White RAL9003
Optical Material
Optical Finish
Termination
5x2x2.5mm sq. Push In Terminal
Driver - Integral or Remote
Integral
PACKAGING
Carton Dimensions (mm)
Quantity per Outer Carton
Total Weight incl. Carton (Kg)
LUMINAIRE PERFORMANCE
Energy Rating
Luminaire Lumens (lm)
6634 / 8084 / 9733 / 11234
Power Consumption (W)
38.9 / 47.4 / 57.8 / 67.7
Efficacy (l.lm/c.W)
171 / 171 / 168 / 166
Operating Temp. (Min/Max)
-20°C to 45°C
LIGHT SOURCE
Type
LED
Correlated Colour Temp.
4000
Colour Rendering Index (CRI)
>80
Lumen Depreciation
L80 100000
SDCM
<3
ELECTRICAL INPUT
Voltage (V)
220-240V AC
Operating Frequency (Hz)
50
Inrush
<25A
Drivers per MCB *
B10=4 B16=8 C10=8 C16=16
Class
Class 1
Power Factor (PF)
>0.95
Cable Entry
Ends
ELECTRICAL OUTPUT
Forward Current (mA)
-
Forward Voltage (Vf)
EMERGENCY DATA
Mode of Operation
Battery Duration
Battery Type
Battery Specification
Ballast Lumen Factor (BLF)
DIMMING
DALI
Switch Dim
Corridor Function
Other
SENSORS
Microwave
PIR
PEC
STANDARDS/APPROVALS
CE / Cert of Conformity
Yes / Yes
Accreditations
BARCODE / E No. / S No.
EAN Number
5056673204462
E Number
7218732
S Number
4314365
