GENERAL INFORMATION
Product Code
NTM/4/40-55/DD/840
Product Range
TEMPE PRO
Product Category
Surface Mount
Fixing Method
Surface /Suspended
IP Rating
23
IK Rating
Warranty
7 Years
DIMENSIONS/WEIGHT
Dimensions
W: 92 - H: 50 - DEPTH: - DIAMETER:
Cut-out Size (mm)
Product Weight (kg)
Construction
Body Material
Steel
Body Colour
White RAL9003
Optical Material
Optical Finish
Termination
7x2x2.5mm sq. Push In Terminal
Driver - Integral or Remote
Integral
PACKAGING
Carton Dimensions (mm)
Quantity per Outer Carton
Total Weight incl. Carton (Kg)
LUMINAIRE PERFORMANCE
Energy Rating
Luminaire Lumens (lm)
6634 / 8084 / 9733 / 11234
Power Consumption (W)
38.9 / 47.4 / 57.8 / 67.7
Efficacy (l.lm/c.W)
171 / 171 / 168 / 166
Operating Temp. (Min/Max)
-20°C to 45°C
LIGHT SOURCE
Type
LED
Correlated Colour Temp.
4000
Colour Rendering Index (CRI)
>80
Lumen Depreciation
L80 100000
SDCM
<3
ELECTRICAL INPUT
Voltage (V)
220-240V AC
Operating Frequency (Hz)
50
Inrush
<25A
Drivers per MCB *
B10=4 B16=8 C10=8 C16=16
Class
Class 1
Power Factor (PF)
>0.95
Cable Entry
Ends
ELECTRICAL OUTPUT
Forward Current (mA)
-
Forward Voltage (Vf)
EMERGENCY DATA
Mode of Operation
Battery Duration
Battery Type
Battery Specification
Ballast Lumen Factor (BLF)
DIMMING
DALI
Yes
Switch Dim
Yes
Corridor Function
Other
SENSORS
Microwave
PIR
PEC
STANDARDS/APPROVALS
CE / Cert of Conformity
Yes / Yes
Accreditations
BARCODE / E No. / S No.
EAN Number
5056673204493
E Number
7218735
S Number
4314368
